The H803 SE Handheld Label Printer 80mm Wireless WiFi is a thermal printer featuring 203 DPI, 80-120mm/s Speed.
Built for harsh environments, the H803 SE features IP54 dust and splash protection, 1.5-meter drop resistance, and a 50KM-rated print head life. It supports the ESC/POS command set, making it compatible with virtually any mobile POS or label printing app. The 128x32 OLED display and Type-C fast charging complete a professional mobile printing solution. CE and FCC certified, with full OEM and ODM customization available.
| Model | H803 SE |
| Print Method | Direct Thermal Line |
| Resolution | 203 dpi |
| Print Width | 2-inch and 3-inch (25-80mm) |
| Print Speed | 80-120mm/s |
| Interfaces | USB (Type-C) + Bluetooth 5.0 (Standard); USB + Bluetooth + WiFi (Optional) |
| NFC | Yes - Quick Pairing |
| Print Head Life | 50KM |
| Buffer | DRAM: 8M, Flash: 16M |
| Command Set | ESC/POS |
| Paper Type | Gap, Continuous, Black-mark Paper |
| Paper Width | 25mm - 80mm |
| Paper Roll Diameter | Max. 50mm |
| Paper Thickness | 0.06 - 0.17mm |
| Paper Off Way | Top Paper Out, Tear Off |
| Character Set | GB18030, BIG5, KSC5601 (TTF Vector Font Supported) |
| 1D Barcode | CODE128, EAN128, ITF, CODE39, EAN13, EAN8, CODABAR, POSTNET, UPC-A, UPC-E, etc. |
| 2D Barcode | PDF417, QR Code |
| Display | 128 × 32 OLED Black/White Display |
| Operation Buttons | POWER, FEED |
| Battery | 2600mAh / 7.4V Rechargeable Li-ion |
| Continuous Printing | ≥230 Meters (12.5% Print Density) |
| Standby Time | ≥160 Hours |
| Battery Cycle Life | 300 Cycles (≥80% Capacity Retention) |
| Charge Time | Approx. 4 Hours (Type-C Fast Charging) |
| Power | Input: AC 100-240V 50/60Hz, Output: DC 5V/2A |
| Protection Rating | IP54 (Dust & Splash Resistant) |
| Drop Resistance | 1.5 Meters |
| Work Environment | Temperature: 5-40°C, Humidity: 20-90% |
| Storage Environment | Temperature: -25-55°C, Humidity: 20-93% |
| Weight (without battery) | 300g |
| Weight (with battery) | 410g |
| Dimensions | 116 × 114 × 62.5mm |
| Software | Android/iOS Label Editing APP, SDK |
| Accessories | USB Cable × 1, USB Power Charger × 1, Manual × 1 |
| Certifications | CE, FCC, RoHS |
First 3 orders no MOQ for full testing; from 4th order MOQ 100 units. OEM MOQ: 100 PCS.
Upon payment: Sample 1-3 days; Mass 7-25 days (by qty & model); OEM/ODM 10-45 days.
Sample fee is charged. Sample fee is deductible from your future mass order.
12-month warranty (non-human damage) or RMA spare-parts ratio. Tech support & free software updates included.
CE / FCC / RoHS certified for global market placement.
Supported — logo, firmware, and packaging customization available.
Watch the H803 SE handheld label printer survive 10 drops from 1.5 meters in this rugged durability test — a wireless WiFi label printer built for retail, warehouse and field labeling. Visit our Operation Videos center for the full product playlist.
Watch VideosGet up and running in minutes. Covers unboxing, setup, media loading, and the first test print.
View ManualComplete reference covering commands, interface configuration, and troubleshooting.
View ManualNeed the full documentation library? Browse all manuals, datasheets, and drivers in our Manuals & Datasheets Center →
View All Manuals & DatasheetsThe H803 SE Handheld Label Printer 80mm Wireless WiFi is built on an open, integration-friendly platform with standard command-set support, making it easy to connect with your existing POS software, kiosk app, or ERP system. Below is the compatibility overview.
Industry-standard command compatibility — works with most label/receipt design software and middleware.
USB, Ethernet, Serial, and USB Host are standard for flexible host and peripheral connection.
Optional Bluetooth and Wi-Fi modules for mobile and networked deployments.
Compatible with mainstream POS, WMS, and retail applications via standard APIs.
Supports barcode scanner, keyboard, cash drawer, and external display via USB Host / I/O ports.
SDK, drivers, and sample code available for custom application development.
Access our developer resources to build, test, and deploy your H803 SE Handheld Label Printer 80mm Wireless WiFi integration.
Bluetooth 5.0 and optional WiFi deliver flexible wireless printing from Android, iOS, and Windows devices. Print receipts, labels, and waybills cable-free from a phone, tablet, or PC anywhere on the floor.
The 2600mAh / 7.4V Li-ion battery delivers 230+ meters of continuous printing and 160+ hours of standby per charge. Type-C fast charging reaches full capacity in approximately 4 hours.
IP54 dust and splash protection combined with 1.5-meter drop resistance ensures reliable operation in logistics, warehouse, and outdoor field environments. Built to withstand tough daily use.
Built-in ESC/POS, TSPL, and CPCL emulation makes the H803 SE compatible with the widest range of label, receipt, and waybill software—from courier apps to warehouse WMS—without custom drivers. One printer covers three command worlds for true plug-and-play.
Built-in NFC module enables instant pairing with NFC-enabled devices. Simply tap to connect, eliminating complex Bluetooth setup procedures for faster deployment in the field.
128x32 OLED display shows printer status and settings at a glance. At only 410g and 116x114x62.5mm, the H803 SE fits in a bag or mounts on a belt for truly mobile workflows.
The H803 SE portable thermal printer is tested and certified for hardware compliance, suitable for export and deployment in multiple international markets.
Compliant with European health, safety, and environmental protection requirements for placement on the EU market.
Meets United States Federal Communications Commission standards for electromagnetic interference and radio frequency emissions.
Compliant with the Restriction of Hazardous Substances Directive, ensuring environmentally responsible manufacturing.
We provide flexible OEM and ODM services for the H803 SE portable thermal printer, helping partners build branded mobile printing solutions for their markets.
Silk-screen logo, custom color finishes, and branded packaging to match your corporate identity.
Custom firmware adjustments, ESC/POS command set compatibility, and SDK support for software teams.
Choose between standard USB+Bluetooth or optional USB+Bluetooth+WiFi configurations to match regional market demands.
Optional NFC module, battery capacity variants, and regional plug types for global distribution.
MOQ-flexible pricing, custom retail boxes, and accessories bundles for bulk orders.
Standard 12-month warranty, remote technical support, and spare parts service for global customers.
Compare the H803, H803 SE, and H803 PLUS portable printer variants to find the right fit for your business.
| Model | Type | Print Width | Speed | Connectivity | Best For |
|---|---|---|---|---|---|
| H803 | 80mm Portable | 25-80mm | 80-120mm/s | BT 5.0 + USB + NFC | Mobile billing, logistics, field service |
| H803 SE | 80mm Portable Mobile Printer | 25-80mm | 80-120mm/s | BT 5.0 + USB | ESC/POS mobile receipt & label printing |
| H803 PLUS | 80mm Portable (Linerless) | 25-80mm | 80-120mm/s | BT 5.0 + USB (WiFi opt.) | Linerless label, outdoor field ops |
The H803 SE 3inch portable thermal printer is a versatile mobile printing solution for businesses that need reliable, on-the-go receipt, label, and waybill output.
Print shipping labels, waybills, and delivery receipts on the go. The 50mm paper roll compartment and Bluetooth 5.0 connectivity integrate seamlessly with courier apps.
Explore Logistics Solutions →Mobile receipt printing and inventory label generation for retail chain stores. NFC quick pairing enables rapid deployment across multiple store locations.
Wireless kitchen order ticket and receipt printing from tablets or smartphones. The IP54 rating handles kitchen humidity and splashes with ease.
Issue printed tickets and service receipts at event gates, parking lots, and field service sites. The 1.5m drop resistance and 2600mAh battery support all-day outdoor use.
Print guest folios and receipts at hotel check-in counters or poolside. Compact 410g design fits in a pocket or apron for mobile staff workflows.
Contact our team for datasheets, OEM/ODM options, pricing, and volume discounts. We are ready to help you configure the right portable thermal printer for your business.
